UL891 Switchboard Solution
The Susol UL891 switchboard solution meets UL67/UL891 certification standards for bus straps and interiors utilizing UL489 MCCBs.There are five types of interiors, three types of bus straps, and a wide range of MCCBs available which allow flexibility during the development and selection stage for new panels. It is a cost effective and allows for safe installation and interchangeability.
Features
- UL67/UL891 Panelboards
- UL489 Molded case circuit breakers
- Main bus, 1200/2000/2400/4000/6000A copper
- Branch-bus direct connection
- Up to 1200A breaker mounted as a branch device
- Double branched 150, 250 and 400AF breakers
- The interior maximum short circuit interrupting rating 100kA at 600Vac
- Individual breaker Protection cover plates
Specification
